Future proof your alarm communication
Following the successful series IRIS-800, IRIS Touch and IRIS Touch NG, IRIS-4 is now the fourth generation of the Alarm over IP product range.
The IRIS system provides a simple, reliable and proven way to convert existing, analogue, security installations to modern digital IP communications, and has become one of Europe’s most widely used security system – trusted by security installers, monitoring centre operators and end-users.
Now, with support for 4G and a new processor enabling double the capacity and speed – improvements making the IRIS-4 terminal family future proof in regards to changes in the mobile networks and ready for new technologies.
All IRIS-4 products are tested and certified by the renowned VdS laboratories to the latest and highest European standards for alarm transmission.
Specifications AddSecure IRIS-4 Series
| FEATURE | 160 | 200 | 220 | 240 | 400 | 420 | 440 | 620 | 640 |
|---|---|---|---|---|---|---|---|---|---|
| Fire retardant enclosure | ■ | ■ | ■ | ■ | - | - | - | - | - |
| Battery backup | >15h | - | - | - | - | - | - | - | - |
| Touch screen | - | ■ | ■ | ■ | ■ | ■ | ■ | - | - |
| Security Grade | 2 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| EN54-21 CPR Fire approved | - | - | - | - | ■ | ■ | ■ | - | - |
| Ethernet ports | 1 | - | 1 | 1 | - | 2 | 2 | 1 | 1 |
| WiFi | ■ | - | - | - | - | - | - | - | - |
| 2/3/4G | ■ | ■ | - | ■ | ■ | - | ■ | - | ■ |
| Dial Capture | ■ | ■ | ■ | ■ | ■ | ■ | ■ | - | - |
| Relays | 3 | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Inputs (pins) | 4 | 4 | 4 | 4 | 4 standard +12 with add-on expansion board | 4 standard +12 with add-on expansion board | 4 standard +12 with add-on expansion board | 6 | 6 |
| Serial RS485 | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ |
| Serial TTL | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ |
| RS232 (basic ) | ■ | ■ | ■ | ■ | 1x full or 2x basic | 1x full or 2x basic | 1x full or 2x basic | 2x basic | 2x basic |
| SMS text messaging | ■ | ■ | - | ■ | ■ | - | ■ | - | ■ |
| Multi language menus | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ■ |
| VoIP & SIP services | ■ | ■ | ■ | ■ | ■ | ■ | ■ | ||
| CAN bus | - | - | - | - | ■ | ■ | ■ | - | - |
| Certifications |
|---|
| EN 50131, EN 50136 VdS Certified) The terminals are compliant with the requirements of European standards: EN 50131-1: 2006+A2:2017 & EN 50131-10:2014 EN 50136-1: 2012 & EN 50136-2: 2013 Environmental Class II |
